Description
Virtual control technology is a data acquisition and data management system for controlling and monitoring building and system states.
The data is not stored locally, but is available to manufacturers, service companies and operators as a web-based portal solution worldwide and without time limits.
- Functional and performance description:
– Overview of all operating data in real time, central consumption recording and easier energy management
– Accurate data logging and automatic dispatch of reports as proof in accordance with legal requirements
– Automatic fault detection and alarm forwarding via SMS or e-mail
– Analysis tool for graphical and tabular evaluation of the data
– Central management of access authorizations, multi-client capability and user roles
– Reliable logging and traceability of changes - Security:
– SSL encryption of all data for the web application
– Providing the web application in the server system via upstream web proxy
– Protection of server systems via firewalls (IP filtering), Virtual Private Network (VPN) connection via GPRS network
– Central point for system administration, user authentication via login and password
– User permissions regulate the access rights of users to all applications and data sets
– Remote maintenance of existing systems
System requirements
- BACnet project planning
- Creation of device graphics and system diagrams
- Internet access via DSL, GSM or telephone landline
- Internet capable computer with standard browser (PC, Notebook, PDA, iPad, …)
- New installations (SE-Elektronic):
– From E-DDC3.2 with firmware version >3.03.08 - Existing installations (SE-Elektronic):
– Connection of A-, B- and E-DDCs with the Gateway GW-BC-SE
– From E-DDC3.2 with firmware version >3.03.08 - Third-party systems:
– Connection of external systems via a gateway from SE-Elektronic - Supported bus protocols:
– BACnet MS/TP or IP: ROUTER-BC, ROUTER-GSM
– Modbus RTU (Master or Slave): GW-BC-SE, ROUTER-GSM
Easy installation, cost-effective operation.
